How to Set Up the TryItOn Retailer Widget on Shopify and Magento

What Shoppers Will See

Once installed, the widget lets shoppers upload a selfie and view a realistic try-on result without leaving your store. Below are example before-and-after results using the same visual assets already featured on the TryItOn homepage.

Before You Start

Step 1: Prepare the Backend

Start inside the TryItOn app environment. Apply the widget schema, add the session secret, and seed the retailer record plus allowed origins.

npm run db:push

WIDGET_SESSION_SECRET=replace-with-high-entropy-secret

WIDGET_RETAILER_EXTERNAL_ID=ret_demo \
WIDGET_RETAILER_NAME="Demo Store" \
WIDGET_RETAILER_MONTHLY_CAP=500 \
WIDGET_RETAILER_ORIGINS="https://shop.demo.com,https://www.shop.demo.com" \
npm run widget:seed

What this does: it creates the retailer identity the widget expects, limits usage for the account, and prevents unauthorized domains from opening sessions.

Step 2: Add the Widget Mount to Your PDP

On the retailer product detail page, add the widget container where you want the Try It On button to appear.

<div
  id="tryiton-widget"
  data-retailer-id="ret_demo"
  data-sku="sku_123"
  data-image-url="https://cdn.shop.demo.com/products/sku_123.jpg"
  data-variant-id="blue_m"
  data-product-name="Linen Shirt"
  data-price="69.00"
  data-currency="USD"
></div>

The widget reads product context from these data-* attributes. The minimum required fields are listed below, but the extra context improves the shopper experience and analytics quality.

Step 3: Load the Widget Script

Add the retailer script once on the PDP so the widget can initialize automatically.

<script async src="https://cdn.tryiton.app/widget/v1.js"></script>

Shopify Quick Start

If your store runs on Shopify, the fastest path is to add the widget mount to your product template and load the script once. Then, on variant change, update the widget attributes and remount it. For merchant-facing positioning, pair this setup guide with our virtual try-on for Shopify landing page.

<div
  id="tryiton-widget"
  data-retailer-id="{{ settings.tryiton_retailer_id }}"
  data-sku="{{ product.selected_or_first_available_variant.sku | escape }}"
  data-variant-id="{{ product.selected_or_first_available_variant.id }}"
  data-image-url="{{ product.selected_or_first_available_variant.featured_image | image_url: width: 1200 | prepend: 'https:' }}"
  data-product-name="{{ product.title | escape }}"
  data-price="{{ product.selected_or_first_available_variant.price | money_without_currency | replace: ',', '' }}"
  data-currency="{{ shop.currency }}"
></div>

<script>
  (function () {
    var mount = document.getElementById('tryiton-widget');
    if (!mount) return;

    function remount() {
      mount.removeAttribute('data-tryiton-mounted');
      mount.innerHTML = '';
      window.TryItOn?.init({
        retailerId: mount.getAttribute('data-retailer-id')
      });
    }

    var readyTimer = setInterval(function () {
      if (window.TryItOn?.init) {
        clearInterval(readyTimer);
        remount();
      }
    }, 50);

    document.addEventListener('variant:change', function (event) {
      var variant = event.detail && event.detail.variant;
      if (!variant) return;

      mount.setAttribute('data-sku', variant.sku || '');
      mount.setAttribute('data-variant-id', String(variant.id || ''));
      mount.setAttribute('data-image-url', variant.featured_image && variant.featured_image.src ? variant.featured_image.src : mount.getAttribute('data-image-url') || '');
      mount.setAttribute('data-price', (variant.price / 100).toFixed(2));
      remount();
    });
  })();
</script>

Shopify implementation model: phase 1 is a theme snippet or section-level integration on the PDP. Phase 2 is a proper Shopify app extension block so merchants can enable it from Theme Customizer without editing theme files manually.

Magento / Adobe Commerce Quick Start

If your storefront runs on Magento Open Source or Adobe Commerce, the cleanest rollout is to place the widget inside the product view layout, render the mount in a PHTML template, and keep CSP approvals in the theme or module scope. The platform-specific buying context lives on our Magento enterprise page.

<referenceContainer name="product.info.main">
  <block
    class="Magento\Framework\View\Element\Template"
    name="tryiton.widget"
    template="Vendor_Module::tryiton/widget.phtml"
    after="product.info.addtocart"
  />
</referenceContainer>

<?php
$product = $block->getLayout()
  ->getBlock('product.info')
  ?->getProduct();
?>
<div
  id="tryiton-widget"
  data-retailer-id="ret_adobe_commerce"
  data-sku="<?= $block->escapeHtmlAttr($product?->getSku() ?? '') ?>"
  data-image-url="<?= $block->escapeUrl($product?->getImageUrl() ?? '') ?>"
  data-product-name="<?= $block->escapeHtmlAttr($product?->getName() ?? '') ?>"
  data-price="<?= $block->escapeHtmlAttr((string) ($product?->getFinalPrice() ?? '')) ?>"
  data-currency="<?= $block->escapeHtmlAttr($block->getCurrentCurrencyCode()) ?>"
></div>
<script async src="https://cdn.tryiton.app/widget/v1.js"></script>

require(['jquery'], function ($) {
  $(document).on('updateMsrpPriceBlock', function () {
    var mount = document.getElementById('tryiton-widget')
    if (!mount || !window.TryItOn?.init) return

    mount.removeAttribute('data-tryiton-mounted')
    mount.innerHTML = ''
    window.TryItOn.init({
      retailerId: mount.getAttribute('data-retailer-id')
    })
  })
})

Magento implementation model: phase 1 is theme-level layout XML plus PHTML insertion on the PDP. Phase 2 is a packaged Adobe Commerce module that registers the block, CSP policy updates, and admin configuration cleanly across environments.

Step 4: Add Optional Theme and Analytics Configuration

If you want custom styling or event callbacks, initialize the widget with a theme object and analytics hook after loading the script.

<script>
  window.TryItOn?.init({
    retailerId: 'ret_demo',
    analytics: {
      endpoint: 'https://www.tryiton.app/api/widget/events',
      onEvent: (name, payload) => console.log(name, payload),
    },
    theme: {
      buttonBg: '#111827',
      buttonColor: '#ffffff',
      buttonRadius: '12px'
    }
  })
</script>

Step 5: Confirm the Required Data Attributes

Do not launch without these three fields on the widget mount:

• data-retailer-id
• data-sku
• data-image-url

If the button does not render, missing product attributes are the first thing to check.

Step 6: Update Your CSP

Your retailer domain must allow the widget script, iframe, and API traffic. Update your Content Security Policy to include the TryItOn domains below.

Content-Security-Policy:
  script-src 'self' https://cdn.tryiton.app;
  frame-src https://www.tryiton.app;
  connect-src 'self' https://www.tryiton.app;

Step 7: Verify the Integration End to End

Before launch, walk through the full flow on an approved retailer origin:

1. Open a PDP that contains the widget mount.
2. Confirm the Try It On button appears.
3. Click the button and verify a widget session is created.
4. Complete one try-on and confirm the modal flow returns a result.
5. Check that widget events are recorded if analytics are enabled.

Troubleshooting Checklist
